Guangzhou Mankun Electronic Co., Ltd. is a professional in the designing, and producing LED modules, LED strips, and finish LED products.
4 Years
| Ask Lasest Price | |
| Brand Name : | ManKun |
| Certification : | ROHS UL |
| Price : | Negotiation |
| Payment Terms : | Negotiation |
| Supply Ability : | 10000 SET /Month |
| Delivery Time : | 10-15 work days |
500W Outdoor IP67 Waterproof Street Light Motion Sensor Flood Light
5 Years Warranty Led Street Light Motion Sensor Flood Light Outdoor CB Approved
The features of 50w-200w led flood light series.
| Part Number | LY-HB0601 | LY-LHB0602 | LY-HB0603 | LY-HB0604 |
| Wattage | 50w | 100W | 150W | 200W |
| Lumen Output | 7500-8000lm | 15000-16000lm | 22500-24000lm | 30000-32000lm |
| Luminous Efficacy | 150-160lm/W | 150-160lm/W | 150-160lm/W | 150-160lm/W |
| Input Voltage | 90-305V AC/200-240V AC 50-60Hz | |||
| Beam Angle | 10°/25°/45°/60°/90°/145x90°/150x70° | |||
| CCT | 2800~6500K | |||
| CRI | ≥70 or ≥80 | |||
| IP & IK Rating | IP66&IK10 | |||
| Surge protection | Line earth 4KV, Line-line 10KV/20KV available | |||
| Power factor | >0.95 | |||
| Power efficiency | 88% | 92% | 92% | 92% |
| THD | <15% or <20% | |||
| Working temperature | -40℃~50℃ 20%~90% H.R | |||
| Storage temperature | -40℃~85℃ 10%~90% H.R | |||
| Housing material | AL6063-T5 | |||
| Housing color | Black | |||
| Insulation | Class 2 | |||
| Options | PWM /DALI/1-10V/Timming | |||
| Lifespan | >50,000Hrs | |||
| Lamp size | 260*105*195mm | 260*168*195mm | 260*258*195mm | 348*260*195mm |
| Packing | 4pcs/ctn 450*280*215mm | 3pcs/ctn 600*310*255mm | 2pcs/ctn 585*310*255mm | 1pcs/ctn 400*310*255mm |
| N.W. | 2.5kg | 3.0kg | 4.0kg | 5.0kg |
The features of 250w-500w led flood light series.
| Wattage | LY-HB0605 | LY-HB0606 | LY-HB0608 | LY-HB0610 |
| Lumen Output | 250W | 300W | 400W | 500W |
| Luminous Efficacy | 37500-40000lm | 45000-48000lm | 60000-64000lm | 75000-78000lm |
| Input Voltage | 150-160lm/W | 150-160lm/W | 150-160lm/W | 150-160lm/W |
| Beam Angle | 10°/25°/45°/60°/90°/145x90°/150x70° | |||
| CCT | 2800~6500K | |||
| CRI | ≥70 or ≥80 | |||
| IP & IK Rating | IP66&IK10 | |||
| Surge protection | Line earth 4KV, Line-line 10KV/20KV available | |||
| Power factor | >0.95 | |||
| Power efficiency | 92% | 92% | 92% | 92% |
| THD | <15% or <20% | |||
| Working temperature | -40℃~50℃ 20%~90% H.R | |||
| Storage temperature | -40℃~85℃ 10%~90% H.R | |||
| Housing material | AL6063-T5 | |||
| Housing color | Black | |||
| Insulation | Class 2 | |||
| Options | PWM /DALI/1-10V/Timming | |||
| Lifespan | >50,000Hrs | |||
| Lamp size | 438*260*195mm | 520*258*195mm | 520*348*195mm | 520*438*195mm |
| Packing | 1pcs/ctn 490*310*255mm | 1pcs/ctn 570*310*255mm | 1pcs/ctn 570*400*260mm | 1pcs/ctn 570*490*255mm |
| N.W. | 6.0kg | 9.0kg | 11kg | 13kg |
Using neutral packing cartons, also accept customize packing as clients' requirements.
| Power | Packing size | Gross weight | Packing way |
| 50W | 32 * 21 * 22 cm | 4.5 kg | 2pcs/carton |
| 100W | 34 * 25 * 16 cm | 3.8 kg | 1pcs / carton |
| 150W | 34 * 30 *16 cm | 4.9 kg | |
| 200W | 39 * 34 * 16 cm | 6.0 kg | |
| 300W | 64 * 32 * 18 cm | 9.6 kg | |
| 400W | 64 * 43 * 18 cm | 12.0 kg |
Trade terms
> Trade Term: EXW, FOB, CIF, DDU. DDP.
> MOQ: 1pcs
> Sample Availability: Yes
>Payment: T/T, Western Union, Paypal
> Normal Lead Time: 7 days for sample order; 15 days for bulk order
> Payment Terms: 30% before production, 70% before delivery
> Discount: For bulk order.
> Port: Shenzhen
> Shipment: By Sea / Air / Express
|
|
