SMD 3535 LED Module PCB Aluminum Base Custom Made Circuit Boards
In Stock 20mm Star Aluminum Base With Smd 3535 Led PCB Module Pcb Assembly
Prouduct display
Type | Aluminum PCB 17739 |
Base Material | Aluminum |
Copper Thickness | 35um |
Board Thickness | 1.2/1.5/2.0MM |
Min. Hole Size | 0.2mm |
Min. Line Width | 0.1mm |
Min. Line Spacing | 0.08mm |
Surface Finishing | HASL |
Board Size | Customized |
Product name | Aluminum PCB |
Thermal Conductivity | 1.0-3.0W/m.k |
Breakdown Voltage | 2-4KV |
Silkscreen Color | Black or white |
Solder mask | White |
Wattage | Customized |
PCB size | Customized |
High thermal conductivity of aluminum substrate Certificate: Raw materials and final PCB are all
fully accord with UL standard.
Applicable products: Indoor lighting such as bulb lamp, sky lamp,
downlight, panel lamp, etc.
PCBA Capabilities | |
PCBA CapabilitiesTurnkey PCBA | PCB+components sourcing+assembly+package |
Assembly details | SMT and Thru-hole, ISO SMT and DIP lines |
Lead Time | Prototype: 15 work days. Mass order: 20~25 work days |
Testing on products | Flying Probe Test, X-ray Inspection, AOI Test, Functional test |
Quantity | Min quantity: 1pcs. Prototype, small order, mass order, all OK |
Files needed | PCB: Gerber files(CAM, PCB, PCBDOC) |
Components: Bill of Materials(BOM list) | |
Assembly: Pick-N-Place file | |
PCB Panel Size | Min size: 0.25*0.25 inches(6*6mm) |
Max size: 20*20 inches(500*500mm) | |
PCB Solder Type | Water Soluble Solder Paste, RoHS lead free |
Components details | Passive Down to 0201 size |
BGA and VFBGA | |
Leadless Chip Carriers/CSP | |
Double-sided SMT Assembly | |
Fine Pitch to 0.8mils | |
BGA Repair and Reball | |
Part Removal and Replacement | |
Component package | Cut Tape,Tube,Reels,Loose Parts |
PCB assembly process | Drilling-----Exposure-----Plating-----Etaching &
Stripping-----Punching-----Electrical Testing-----SMT-----Wave |
|
|
